C-100 wire rope core tape permeability tester

Overview:

C-100 type steel wire rope core conveyor belt permeability tester conforms to the test requirements of GB21352-2008 Appendix B and MT668-2008 Appendix C. It is a test device to test the degree of penetration of rubber inside the steel wire rope core of the conveyor belt.

Technical Parameters.

Supply Voltage

AC220V 50HZ

input power

50KW

Test medium

Air, air pressure 4-5KPa

Input gas source detection

0-1000 KPa, detection accuracy: ±1 KPa

Breathability testing

0.0-50.0 KPa, detection accuracy: ±0.1Kpa

specimen size

400 (mm) x 150 (mm)

Specimen thickness

10-40 (mm)

Tester external dimensions

900 (L) x 450 (W) x 600 (H)

weights

160KG
