DL-100KN computer-controlled tensile testing machine

Overview.

DL-100 computer-controlled tensile testing machine is a high-precision load testing machine, equipped with liquid crystal display, adopting microprocessor control and integrated, digital measurement and control technology, and can be processed and printed.DL-100KN computer-controlled tensile tester is suitable for the conveyor belt whole wire rope pulling off as well as the whole belt dumbbell-like pulling off and other performance testing. Equipped with the corresponding tooling, it can automatically obtain the maximum test force, tensile strength, elongation stress, modulus of elasticity, constant elongation stress, constant stress elongation and other parameters. The testing machine is powerful, accurate in data processing, simple in operation and convenient in use and maintenance. It meets the test requirements of GB/T 3690-2009 "Test Method for Full-Thickness Tensile Strength, Elongation at Pull-off and Elongation at Reference Force of Fabric Core Conveyor Belt" standard.

Technical Parameters.

Maximum load of the tester

100kN
Load Cell Capacity

100kN (optional capacity sensor up to 100kN)

Precision grade of the whole machine

0.5 level
Force Measurement Accuracy

±0.005

Effective force range

1%-100%
Speed measurement range

1-500mm/min stepless speed regulation (or customized)

Tester resolution

1/100000
Displacement measurement accuracy

±0.002

Effective test stroke

800mm
Dimensions of mainframe (L×W×H)

800mm×1080mm×2700mm

electrical machinery

Three-phase 380V, 50HZ
Main body weight

Approx. 1000kg
