DL-2KN computer-controlled tensile testing machine

Overview.

DL-2KN computer-controlled tensile testing machine is a high-precision load testing machine, equipped with liquid crystal display, using microprocessor control and integrated, digital measurement and control technology, and can be processed and printed information.DL-5KN computer-controlled tensile testing machine is suitable for conveyor belt whole core dumbbell-like tensile testing performance, etc. With the corresponding tooling, it can automatically obtain the maximum tensile strength, elongation stress, elastic modulus, constant elongation stress, constant stress elongation and other parameters. Equipped with the corresponding tooling, it can automatically obtain the maximum test force value, tensile strength, elongation stress, modulus of elasticity, constant elongation stress, constant stress elongation and other parameters. The testing machine is powerful, accurate in data processing, simple in operation and convenient in use and maintenance. It meets the test requirements of GB/T 528-2009 "Determination of Tensile Stress-Strain Properties of Vulcanized Rubber or Thermoplastic Rubber" ISO37:2005 standard.

Technical Parameters.

Maximum load of the tester

2kN
Load Cell Capacity

2kN (optional capacity sensor up to 2kN)

Precision grade of the whole machine

0.5 level
Force Measurement Accuracy

±0.005

Effective force range

1%-100%
Speed measurement range

1-200mm/min stepless speed regulation (or customized)

Tester resolution

1/100000
Displacement measurement accuracy

0.01mm

Effective test stroke

500mm
Dimensions of mainframe (L×W×H)

530mm×525mm×1480mm

power supply

Single-phase 220VAC, 50HZ
Main body weight

Approx. 150kg
