DLRC-1000B Single Wire and Cable Vertical Combustion Tester

DLRC-1000B Single wire and cable vertical combustion tester

Overview:

DLRC-1000B single wire and cable vertical combustion testing machine according to GB/T 18380.11/12, IEC60332-1, JB/T 4278.5, BS, EN test standards. Both ends of the specimen are fixed and vertically placed in a metal cover with metal plates on three sides. It is operated by touch screen, PLC control air and gas flow, electronic igniter to light the torch, make the tip of the blue inner cone touch the test surface and keep the torch and the vertical axis of the specimen at 45°.

Technical parameters:

metal cover	1200mm high, 300mm wide, 450mm deep, open front, closed top and bottom
Combustion box volume	1 m3 (external dimensions 21501200550mm)
fuels	Gas. Methane (customer supplied)
Power consumption of the whole machine	0.6KW
Nominal power 1kw torches
Integrated Burning Lamp Calibration Unit
The machine will automatically stop ignition when the set combustion time reaches the preset time.
Ignition is automatic high-voltage electric
One air mass flow meter, one gas mass flow meter each
Touch screen operation with PLC control of air and gas flow rate
Calibration temperature controller, calibration time, test time digital display table display
