DNP-2A Duplex Dynamic Adhesive Strength Tester for Wire Cord Core Tape/Conveyor Belt

Overview:

This machine can simultaneously determine the dynamic bonding strength index between steel wire rope and rubber in two groups of steel wire rope core conveyor belt by pulling fatigue test method.

Through the transmission, the lower fixture of the bonding strength testing machine rises or falls, and applies a cyclic pulling load to the steel wire rope in the specimen to determine the dynamic bonding strength when a certain number of loading cycles are reached or the bond is broken. And can be done to complete the standard cycle test cycle after the pulling test. The design of this machine is in line with GB21352-2008 Appendix A and MT668-2019 Appendix B standard test use requirements.

This machine consists of industrial control machine, printer, machinery, servo drive system, computer electronic control system of five parts.

Technical parameters :

Induction method

Tension Sensors

maximum load

30KN

Number of workpieces

two-station

Power Breakdown Degree

0.3‰f-S

recurring cycle

5-10 seconds (programmable)

multilingualism

Chinese / English

Output Waveforms

trapezoidal wave

power supply

AC 380 V±10% 3-phase 5-wire system 50Hz±1%

Maximum power consumption

4.6KW

Minimum/maximum load realization

3.6%-36% auto-calculated values for static bonding strength of wire ropes

Weight

1100Kg

Volume (mainframe)

1150×760×1700mm

Test Specifications

ST630-ST7500

Cycle period setting

1-10,000 cycles (programmable)

Ambient temperature/humidity

Laboratory temperature/laboratory humidity
