Features.
- The cutting force is mainly 100KN, 120KN, 160KN, 200KN, 250KN, which can meet the different production requirements of customers.2. It is equipped with an automatic oil lubrication system, which reduces wear and prolongs the service life.
- Adopting electronic time-delay circuit to control the lower limit position of the stroke, high precision, can improve the quality of the product, using the handwheel to adjust the height of the swing arm from the worktable, simple, reliable and convenient.
- The column, swing arm and piston rod are all made of high quality steel, durable.
- Instantaneous cutting by utilizing the inertial energy of the flywheel consumes less energy.
Technical Parameters.
Maximum cutting force |
250KN |
Stroke adjustment range |
5-75mm |
Stroke speed |
0.1m/s |
Distance from the beating plate to the working table |
65-150mm |
Motor power |
1.5kw |
worktop |
500*1000mm |
Swing arm size |
350*550mm |
Overall dimensions |
1000*900*1380mm |
Weight |
1050kg |
