Overview.
MA609/Y Roller Drenching Seal Test Bench (touch screen control) is mainly used for the drenching sealing test of rollers to detect the good or bad drenching sealing performance of rollers. This product is in line with MT821-2006 "Coal Mine Belt Conveyor Roller Technical Requirements" and GB/T10595-2009 "Belt Conveyor" standard use requirements. This machine is suitable for scientific research institutions, conveyor belt machine manufacturers, quality inspection institutes and other units.
Technical parameters:
|
Measuring range of roll diameter |
Ф76-Ф159mm or Ф76-Ф245mm |
| Measuring range of roll length |
≤1000mm |
|
Number of rollers tested |
1 or 2 |
| Power supply |
380V 50HZ |
|
sizes |
1550*1225*1500mm |
| weights |
400 kg |
|
Tilt angle of test bench |
30 degrees |
| Drench flow |
0.45L/min (27L/h), adjustable |
