Technical parameters:
Supply Voltage |
AC220V 50Hz |
power consumption |
3KW |
Test environment temperature |
35±0.2°C |
Sample Reagents |
Propane gas |
style |
Gas hose; natural gas; liquefied petroleum gas, etc. |
Overview:
RQT-02 hose gas permeability tester is suitable for testing and inspecting the gas permeability of the hose connected between the cut-off valve of household gas, liquefied petroleum gas and natural gas decompression device and the combustion appliance in factories and laboratories. The product conforms to the test, detection and use requirements of HG2486-93 standard Appendix A. RQT-02 hose gas permeability test device is based on the HG2486-93 standard Appendix A, Figure A1 shows, using a glass tank will be all kinds of glassware with stainless steel frame support, the glassware containing the specimen gas pipe using stainless steel gas pipe and is equipped with a connector to facilitate the specimen into the gas pipe connection. Operation mode see standard appendix A in A3 test method. Adopt electric heating to heat the water in the tank to 35 ° ± 0.2 ° C and maintain its temperature.
Technical parameters:
Supply Voltage |
AC220V 50Hz |
power consumption |
3KW |
Test environment temperature |
35±0.2°C |
Sample Reagents |
Propane gas |
style |
Gas hose; natural gas; liquefied petroleum gas, etc. |
