Overview.
SGC-I01 Steel Cord Core Conveyor Belt Single Wire Punching and Cutting Machine is a special equipment for the production of adhesive strength test specimen of steel cord core conveyor belt, which is mainly used for cutting single steel wire of conveyor belt, solving the rupture problem of the middle steel wire rope of conveyor belt in the production of specimen, improving the safety coefficient of the specimen production and shortening the production time, the main features: compact equipment, easy and safe operation.
Technical Parameters.
|
blanking force |
30T |
| Punching stroke |
55mm |
|
power supply |
AC220V |
| Maximum power consumption |
0.75KW |
|
Overall dimensions |
600X500X1500 |
| weights |
300kg |
| Maximum punching diameter of wire rope: ∮4-#15 (need to replace the upper blade according to the specifications of the wire rope) Only one No. 6 upper blade is equipped at the factory (the others will be purchased by the user). | |
