SGM-02B Conveyor Belt Intelligent Roller Friction Tester

Overview:

SGM-02B Conveyor Belt Intelligent Roller Friction Tester conforms to GB/T7986-2013 "Conveyor Belt Roller Friction Test Methods" standard and MT450-1995, MT914-2008 and other related standards for testing and inspection use requirements. This machine is suitable for the roller friction test of fabric core flame retardant conveyor belt and other flame retardant conveyor belt. The testing machine adopts intelligent adjustable tensioning force testing device, changing the previous lever tensioning device in the test process, with the friction tape elongation tensioning force is not constant and the weight tensioning device in the test process operation troublesome drawbacks, truly realize the whole test process of the whole closed intelligent control. The use of units should be through the standardized management of equipment, so as to ensure the reliability and continuity of the test results. Patent No.: ZL2012204184176

Technical parameters:

Power of the whole machine

11.5KW

power supply

AC380V 50Hz three-phase five-wire system

Roller motor power

11KW

Roller material

45# steel, nitriding treatment

Drum load speed

200±5r/min

Micro Blower

Power: 220V, 25W

air velocity

2.0±0.1m/s; air flow adjustable

Porous tube diameter: Φ40 (inner diameter), ventilation holes inner diameter Φ: 6mm 21, spacing 13mm

Distance between porous tube and roller: 600mm

weights

1200kg

sizes

Mechanical cabinet 1400*860*1900mm Electronic control cabinet 1500*760*1700mm

Apply tensioning force

The servo system automatically applies the tensioning force, applying range 343N-2000N, not exceeding 2000N, automatic belt breakage detection.

Test time recording range

99 hours, 60 minutes and 60 seconds, digital display adjustable, set time parameter value reached automatically stop.

Temperature range

Room temperature-400°C Automatic over-temperature detection and shutdown, temperature measurement accuracy: ±1°C

Temperature intelligent instrument display, and can print the temperature rise curve.

temperature sensor

Three, (one practical and two spare).
