SL-SGZ01 Conveyor Belt Rolling Resistance Tester

summarize::

SL-SGZ01 conveyor belt rolling resistance testing machine is a roller in the conveyor belt surface rotation, roller rolling and static conveyor belt surface between the resistance generated by the rolling resistance is called rolling resistance, but also can measure the friction coefficient of the conveyor belt on the roller to the roller pressurized under different load conditions of the rolling resistance. SL-SGZ01 conveyor belt rolling resistance testing machine using encoder grating to detect the instantaneous drive displacement. The change value of force is the moving force of the roller, and the friction coefficient of the surface of the conveyor belt is calculated by the computer, as well as the rolling resistance after rolling at a uniform speed.

Technical parameters:

Specimen specification

 (1000*600)mm Maximum loading force 2000N
Maximum Traction Rolling Force 200N Coefficient of Friction Measurement Accuracy

±1 per cent

Loading roller specifications

 Φ100*610mm Rolling resistance detection range 0-200N±1‰
traction line speed 0.03m/s-0.5m/s Maximum power consumption

600W

Horizontal traction speed

 0.03-0.09m/s Input Power AC200V-AC240V. 50HZ/60HZ, (single-phase three-wire system)
Climbing traction speed 0.1-0.3m/s climbing height: not higher than 5mm Overall dimensions

2150X1100X1050 (mm)

Weight

 About 650Kg Maximum loading force

2000N
