SJPR-01A Conveyor belt alcohol blowtorch combustion performance test box

Overview.

SJPR-01A Alcohol Blowtorch Combustion Performance Test Chamber is suitable for scientific research units and factories to do combustion test and flame-retardant evaluation and analysis of various types of flame-retardant and flame-retardant materials under laboratory conditions, and the product meets the requirements of GB/T15907-2008, MT181-1988, MT113-1995, MT668-2019, MT914-2019, MT559-1996 and other national or industry standards for flame-retardant and flame-retardant products test inspection requirements.

Technical Parameters.

power supply

AC220V 50HZ

power consumption

30W

Flame height

150-180 (mm)

Flow Consumption Reagents

2.55±0.15mL/min

reagents

95% ethanol and 5% (V/V) methanol mixture

Overall dimensions

1470(H)*663(W)*663(Th)mm

Interior Dimensions

1070(H)*660(W)*660(T)mm

Alcohol blowtorch angle

90° or 45°

Burning time timing range

1s-99s can be set

Ingredients:

  • Reagents, hoses and flow valves, 10 ml measuring tubes
  • 1000ml reagent container, alcohol blowtorch, sample holder
  • Alcohol blowtorch fast automatic feeding and exiting mechanism
  • electronic control system
  • Timing and temperature measurement systems
  • Fireproof material box
