Specimen specification | Specimen width 75mm Length full width |
Specimen strength | Fabric core≤3000N/mm Steel wire belt≤ST6300 |
Setting range of bending times | 0-300,000 times Settable |
Test time | 200,000 times ≤ 7 days |
Center distance between master and slave rollers | 2500mm |
Maximum travel range of the driven roll | -100mm- +100mm |
Tension control range | 10N-400N Settable |
SLGDW-600/75 dynamic bending fatigue performance testing machine for tubular belt
Tubular belt dynamic bending fatigue performance testing machine, based on the actual application of tubular conveyor belt, the specimen for small tension state of dynamic bending fatigue test. Through the machine test, reflect the rigid fatigue performance of tubular belt, for the production of tubular belt to provide design parameters. The machine adopts touch screen and PLC communication mode for over-programmed control. Tension application is carried out by AC servo system, which can be set for constant tension control. The roller specification can be replaced according to the specimen, and the running data can be exported and printed and saved through U disk.
