SLGSG-600 Tubular Conveyor Belt Transverse Rigidity and Repeat Rigidity Testing Machine

summarize::

SLGSG-600 Tubular Conveyor Belt Transverse Rigidity and Repeat Rigidity Tester is based on Appendix A (Normative Appendix) "Tubular Conveyor Belt Transverse Rigidity Determination Methods" of HG/T4225-2011 "Fabric Core Tubular Conveyor Belt" and HG/T4224-2011 "Steel Wire Cord Tubular Conveyor Belt" standards, and it is designed in conjunction with the actual situation in the application process. The testing machine conforms to the test use method of Appendix A (normative appendix) "Determination Method of Transverse Rigidity of Tubular Conveyor Belt" in the standards of HG/T4225-2011 "Fabric Core Tubular Conveyor Belt" and HG/T4224-2011 "Steel Cord Core Tubular Conveyor Belt". Patent No.: ZL2015202979492.

Technical parameters:

Maximum force value for transverse rigidity

 5.000Kg Accuracy of force measurement for lateral rigidity of upper rollers ±1g
Specimen length 75mm Upper roller up and down movement cycle setting

1-99999 programmable

Rigid Displacement Measurement Accuracy

 ±0.02mm Upper roller up and down movement time setting 10s-5min
Forming Rigidity Vertical Force Measurement Resolution ±0.5g Maximum power consumption

4.0KW

Measuring range of molding rigidity values

 0.001-10.000Kg. Dimensions of the main unit 1310 (L) x 960 (W) x 2180 (H)
Supply Voltage AC220V±10% 50Hz (single-phase three-wire system) Accuracy of force measurement for lateral rigidity of upper rollers

±1g

Maximum molding diameter

∮600mm(Maximum diameter ∮860mm can be produced according to customer's requirements)
