Technical parameters:
|
Main wheel drive motor |
37KW frequency conversion motor speed ratio 1:2 (according to different requirements of the user to change the main motor power and motor type selection, Z4 DC motor) |
| Driven wheel load motor |
37KW DC motor or hysteresis brake (load power is adjusted accordingly to the power of the main motor), the drive adopts the British system. |
|
Master-slave wheel speed |
300-4000r/min (300-4750r/min) stepless adjustable. |
| Driven wheel load |
1KW-22KW (1KW-38.5KW) (according to the main motor power to adjust the load power and load mode) |
|
Torque Detection Range |
1.00-200.00Nm (according to user requirements) |
| Total belt tension |
200N-4400N (using weights to adjust), weights configuration is the choice of pin-type selection, eliminating the need for manual application of moving in the test process, so that the test process to add force accurately, with real-time tracking to automatically detect the test maximum tension |
|
Center distance detection accuracy |
±0.05mm, with laser sensor, automatic detection of center distance |
| Outer circumference detection accuracy |
±0.5mm |
|
Slip rate setting range |
1%-99% |
| Slippage rate detection accuracy |
0.1% |
|
Exposed height detection range |
0.01-20.00mm, automatically detect the exposed height, and automatically fill in the form and save it. Adopt high precision laser sensor, precision 0.01mm |
| Specimen length |
800-4000mm |
|
Pulley detection temperature |
0°C to 250°C, control accuracy ±3°C |
| Belt Pulley Temperature Rise Curve |
Slope accuracy ±3℃/test cycle |
|
Pulley material |
45 steel tempering treatment |
| surface roughness |
RS should be less than 0.8μm |
|
Outside diameter accuracy |
±0.2mm |
| sizes |
2400*1900*650 (mm) |
|
weights |
2.2T |
