- Length measurement method:
It adopts magnetic grid displacement sensor for measurement. According to different specimens corresponding to the standard formula for automatic calculation of the center distance, the effective length of the specimen and the corresponding length of the section line, the amount of change in the center distance, the operator to choose the type of test specimen before the test, you can automatically calculate the above data.
- Multi-wedge measuring range:
Belt length range: 200-1800(mm)
Resolution: 0.005mm (retain two digits after the decimal point)
Center distance measurement accuracy: 0.01mm
- Method and range of tensioning force application:
Adoption of weights to generate specimen tension: 0-1000N
- Weight Configuration Accuracy
Single weight accuracy ±2g (±0.0196N)
- Scope of application: PJ belts
- Equipment size: about 1600(L)*600(W)*1400(H)mm
- Power supply AC220V 50HZ
- The dosage bar for belt wheel testing can be equipped separately according to the user's requirements, and the price is accounted for separately.
- Test test pulley, supplied by the customer.
- Environment of use:
(1) Temperature range: 10°C~35°C
(2) Humidity range: ≤90% without condensation
(3) Altitude: ≤2000m
