XSRZT-01 Air permeability test device for rubber and plastic hoses and assemblies

Overview:

XSRZT-01 type rubber and plastic hose and its combinations of permeability test device for factories, laboratories on the specified time, the volume of gas permeation through the wall of the rubber or plastic hose pipe test and test. The product meets the test, inspection and use requirements of GB/T 18422-2001 standard. The use of glass water tank will be a variety of glassware with stainless steel bracket bracket, glassware containing specimens gas pipe using stainless steel gas pipe and equipped with a quick connector to facilitate the specimen into the gas pipe connection. The test should be run under the air pressure of 1MPa and the temperature specified in GB/T2941. No test should be conducted within 24h of hose production. Before the test, the specimen shall be modulated at least 3h under the selected temperature and humidity according to GB/T 2941.

Technical parameters:

Supply Voltage

AC220V 50Hz
power consumption

2KW

Test environment temperature

23±1°C
Sample Reagents

Water-insoluble test gases

style

Rubber and plastic hoses
